JR-6 Thermal Jacket Remover, for Single Fiber and Ribbon
PN#:
JR-6
MSRP: CALL FOR PRICING
Availability: 8-10 days
MSRP: CALL FOR PRICING
Availability: 8-10 days
- Industry’s First Hot Jacket Remover with IPX1 (Waterproof Protection; Class1) as Defined by JIS C0920
- Easy Fiber Coating Removal
- Lightweight, Shock Resistant, Portable, Rugged Design
- Fast Temperature Stabilization to Reduce Warm-Up Time
- 2-12 Fiber Ribbons or Single Fiber Stripping
- 3-Way Power Supply (Battery, AC/DC, and Fusion Splicer’s 12V DC Output)
- Compact Handheld Design
- Field Replaceable Blades
- Rechargeable Lithium-Ion Battery
- Internally Charges the Battery While Externally Powered
- RoHS Compliant
Applications: CATV/Telecom/LAN/WAN/Data Centers/Medical/Military/Wireless/Broadband
| Applicable Fiber |
Optical Fiber Material • Silica Glass • Fiber Count Coating Thickness
Fiber Count Coating Thickness Single Fiber: Fiber Coating 250 ~ 400µm 2 to 12 Ribbon Fiber: Coating Thickness 300 ~ 400µm Cladding Diameter • 125µm |
| Coating Removal Length | Max.30mm |
| Power Source |
Battery Operation (with BU-JR6B):
Nominal Voltage 7.4V; Nominal Capacity 1620mAh DC Operation (Power Supplied from Fusion Splicer): DC9~15V AC Operation (with ADC-1220S): AC100~240V, 50/60Hz |
|
Operating Duration
|
Approximately 10 Hours |
| Number of Removal Cycles | Approximately 200 on Fully Charged Battery |
|
Battery Charging Time
|
Approximately 2 Hours |
|
Function
|
Temperature Settings: 4 levels
Power Saving Function: Normal Mode / Power Save Mode Battery Remaining Capacity is Indicated in One of Four Levels when JR-6 is Powered On. |
|
Environmental
Conditions |
Operating Condition
Operating Temperature: 0° ~ +40°, Humidity: 0% ~ 95% (Non-Condensing) |
|
Storage Condition:
Storage Temperature: -40° ~ +60°, Humidity: 0% ~ 95% (Non-Condensing) |
|
|
Size
|
45(W) × 138(D) × 38(H) mm |
|
Weight
|
235g (Including Battery) |
